Esri S-57 Viewer

Free add-on available in ArcMap

Download now

ENC Layer replacing the S-57 Viewer add-on

As of February 2023, the new ENC Layer in ArcGIS Pro 3.1 replaces the S-57 Viewer add-on. Transition to ArcGIS Pro to take advantage of its next generation capabilities.

Overview

Esri S-57 Viewer is an add-on that allows ArcMap users to visualize S-57 data in compliance with S-52 standards and specifications for chart content and display aspects.

With the Esri S-57 Viewer, you can

Visualize S-57 data using S-52 standards

  • Query and analyze your S-57 data using various ArcMap
    commands
  • Overlay your S-57 data with other supported ArcGIS formats
  • Apply various S-52 properties such as Color Scheme or Safety Contour Depth

What you get

Supported S-57 Based Product Specifications

  • AML edition 1.0, 2.1, and 3.0
  • ENC edition 3.0, 3.1, 3.1.1, and 3.1.2
  • IENC edition 2.0, 2.1 and 2.2
  • MIO edition 4

User Community

System requirements

The Esri S-57 Viewer add-on requires ArcMap. System requirements are determined by the current product version and platform configuration you are using. Please select the ArcMap version for details:

Common questions

No, S-63 is not supported by the viewer due to IHO regulations. However, support for S-63 is provided by ArcGIS Maritime.

In order to publish S-57 cells, it is recommended you use the ArcGIS Maritime product.

Yes

Yes. Please e-mail maritime@esri.com for additional information regarding Linux support.

Read the Esri S-57 Viewer Install and User Guide for additional information on installation steps and key features. This document is contained in the Esri S-57 Viewer zip file you download from this site. While technical support is not available for free add-ons, you can send questions, suggest enhancements, and report any issues to maritime@esri.com.

Edition 3.2 of the S-52 specification is supported.

Yes, there are control files that can be extended to accommodate custom fields. For additional information e-mail maritime@esri.com.

Yes, the Esri S-57 Viewer can apply update files to the base cell when loading the S-57 dataset.

S-52 is the ENC Presentation Library and is not meant to display AML, IENC, or MIO data. The only data that will be displayed with S-52 is the data that also exists in ENC. That is to say, if your AML object (WRECK) is also supported in the ENC product specification then it should display the same way with S-52. If the AML object is not supported in ENC then it will default to an unknown symbol. S-52 is extensible so any AML objects that do not display can be added to the presentation library. S-52 is fully documented and explains how to do this.
